| Power supply |
220 to 240v AC 2 Amp |
| Power connection |
IEC appliance connector |
| Mains fuse |
2 Amp Slow Blow (T) |
| Power filtering |
Appliance connector with integral EMC filter |
| Size |
600mm (l) x 300mm (d) x 270mm (h) |
| Weight |
> 7 Kg |
| Preamplifier Valves |
Two x STR 7025 (Harma) |
| Effects loop Valve |
One x 12AX7 EH (Electro Harmonix) |
| Input Impedance |
56 Kohms |
| Output configuration |
Class A single ended |
| Output Valves |
One x 6550C (Svetlana), plus one EL34(Svetlana) |
| Output impedance |
4 ohm / 8 ohm switchable |
| Output Power |
35 Watts rms |
| Output connection |
Single ¼” (6.5mm) jack |
| Effects loop |
Valve buffered serial effects loop with adjustable send level. Send and receive connections are both ¼” (6.5mm) jacks. |
| Channel switching |
With footswitch only (included) |
| Features |
Heavy 13 layer birch ply cabinet, Blue crocodile skin effect tolex covering, Steel front grille, Black Steel Corners , Black Steel side bar handles |
| Parts supplied |
3 metre power lead, Footswitch with integral lead and ¼” plug , Loudspeaker lead with integral ¼” plugs , User Instructions |
